VLDF-F-ECO 056-220LPO840 / 0522564
Product Description
Light strip from the VLDF product family. Optical control via , beam pattern symmetric, , light emission . Lamp LED-M installed, Replacement by specialist. The luminaire generates a rated luminous flux of 1797 lm in light colour 840, luminous flux adjustable: No. The long LED service life enables long use with consistent lighting quality. High quality of light thanks to a standard colour tolerance of < 3 SDCM. Housing made of , white, protection rating IP20. With electronic electrical component On/Off. Replacement by specialist. Rated voltage 220 - 240 V AC/DC 50 - 60 Hz.
Order Information
| Item number | 0522564 |
| GTIN | 4029299489101 |
General
| Product category | Light strip |
| Range of application | Education | Office | Retail | Industry |
Dimensions
| Dimension L | 566 mm |
| Dimension B | 36 mm |
| Dimension H | 65 mm |
| Dimension A1 | 400 mm |
| Dimension A4 | 100 mm |
| Dimension K1 | 50 mm |
| Net weight | 0.640 kg |
Mounting
| Mounting type | Attachment |
Housing
| Colour | white |
| Protection class | IP20 |
| Impact resistance | IK06 |
| Glow-wire test | 650 °C |
Electrical version
| Type of control | On/Off |
| Nominal voltage | 220–240 V, 0/50–60 Hz |
| Rated power | 17.0 W |
| Protection class | I |
Lighting technology
| Light output | |
| Light distribution | symmetric |
| Rated luminous flux | 1797 lm |
| Luminaire efficiency | 106 lm/W |
Light source
| Lamp | LED-M |
| Lamp included | Yes |
| Colour rendering index Ra | ≥ 80 |
| Colour temperature | 4000 K |
| Colour location tolerance (SDCM) | < 3 SDCM |
Download Center
Approvals:
| Item number - Designation | Produktbeschreibung | Download | Wishlist |
0202592 -
VLDHSD
|
Wire pendant VLD w. ceiling fixing, lengthw. adj. 1 pc |
|
|
0204639SI -
VLDHSB SI
|
Wire pendant VLD with ceiling fixture, silver, 1 pc. |
|
|
|
0204639 -
VLDHSB
|
Wire pendant VLD with ceiling fixture, 1 pc. |
|
|
0202594SI -
VLDHP 100
|
Tube pendant VLF/VLDF/VLDGT w. canopy, 1000mm, silver |
|
|
|
0202593SI -
VLDHP 050
|
Tube pendant VLF/VLDF/VLDGT w. canopy, 500mm, silver |
|
|
0202597 -
VLDHW
|
Wall fixing for VLD, lengthw. adj, white, 1 pc |
|
|
|
0202597SI -
VLDHW-SI
|
Wall fixing for VLD, lengthw. adj., silver 1 pc |
|
|
0202901 -
VLDHST
|
Wire pend. f. syst. ceil. 24-26mm T, max 10kg, 1.5m, 1 pc |
|
|
0202596 -
VLDHK
|
Chain fixing for VLD, lengthw. adjustment, 1 pc |
|
|
0202590 -
VLDHD
|
Ceiling mounting VLD, H=12.5mm, lengthwise adjustment, 1 pc |
|
|
0202591 -
VLDHS
|
Wire pendant VLD w. ring loop, lengthw. adj. 1 pc |
|
|
Light strip from the VLDF product family. Optical control via , beam pattern symmetric, , light emission . Lamp LED-M installed, Replacement by specialist. The luminaire generates a rated luminous flux of 1797 lm in light colour 840, luminous flux adjustable: No. The long LED service life enables long use with consistent lighting quality. High quality of light thanks to a standard colour tolerance of < 3 SDCM. Housing made of , white, protection rating IP20. With electronic electrical component On/Off. Replacement by specialist. Rated voltage 220 - 240 V AC/DC 50 - 60 Hz.
Order Information
| Item number | 0522564 |
| GTIN | 4029299489101 |
General
| Product category | Light strip |
| Range of application | Education | Office | Retail | Industry |
Dimensions
| Dimension L | 566 mm |
| Dimension B | 36 mm |
| Dimension H | 65 mm |
| Dimension A1 | 400 mm |
| Dimension A4 | 100 mm |
| Dimension K1 | 50 mm |
| Net weight | 0.640 kg |
Mounting
| Mounting type | Attachment |
Housing
| Colour | white |
| Protection class | IP20 |
| Impact resistance | IK06 |
| Glow-wire test | 650 °C |
Electrical version
| Type of control | On/Off |
| Nominal voltage | 220–240 V, 0/50–60 Hz |
| Rated power | 17.0 W |
| Protection class | I |
Lighting technology
| Light distribution | symmetric |
| Rated luminous flux | 1797 lm |
| Luminaire efficiency | 106 lm/W |
Light source
| Lamp | LED-M |
| Lamp included | Yes |
| Colour rendering index Ra | ≥ 80 |
| Colour temperature | 4000 K |
| Colour location tolerance (SDCM) | < 3 SDCM |
