PFSB1500DALG840O0600 / 0931233BH

Ceiling light from the PFSB product family. Optical control via Opal cover, beam pattern symmetric, extremely wide beam, light emission direct. Lamp LED-M installed, Exchange not possible. The luminaire generates a rated luminous flux of 6000 lm in light colour 840, luminous flux adjustable: stepless. The long LED service life enables long use with consistent lighting quality. High quality of light thanks to a standard colour tolerance of < 3 SDCM. Housing made of Plastic, grey, protection rating IP65. Ceiling mounting via fixing clips (enclosed with the luminaire) made of stainless steel, can be snapped onto the luminaire (variable fixing spacing possible). Pendant mounting (chain, cable (accessory, to be ordered separately)) via stainless steel wire fixing clip, can be snapped onto the fixing clips (enclosed with the luminaire). Horizontal wall mounting possible without additional accessories. With electronic electrical component DALI-2. Exchange not possible. Rated voltage 220 - 240 V AC 50 - 60 Hz.

Internal through wiring, 5 x 1.5 mm².

The DALI luminaires have a TouchDim function with which the connected luminaires can be switched on/off and dimmed up/down via push-buttons. The maximum number of jointly controlled TouchDimm luminaires is 5. The total cable length of 25 m must not be exceeded (push-button -> last luminaire). To avoid asynchronisation, the use of a suitable DALI repeater is recommended. Synchronisation by long push-button action: Press and hold the push-button until all the luminaires have dimmed up to maximum brightness.

Note on “Food Hygiene Act”: These luminaires comply with the stipulations of the Food Hygiene Act as defined by Regulation (EC) No. 852/2004 (HACCP) Annex II Chapter I section 2 a, b, Chapter II section 1c relating to luminaires. These are suitable for use in the food industry. A possible restriction of the area of application in the food industry can be found in the food certificate.
