LENSES-EUE M625
Description
Design: Recessed LED single luminaire for 625 x 625 modular ceilings. Rigid luminaire housing in white powder-coated steel (similar to RAL 9016) with square 4-row lens arrays for high-efficiency light yield.Diffuser held in the luminaire housing with spring catches, hinges down on both sides. LED modules formed as a flat board. Mid-power LEDs for even illumination and maximum efficiency. LED driver prefitted in luminaire housing.
Design: Recessed LED single luminaire for 625 x 625 modular ceilings. Rigid luminaire housing in white powder-coated steel (similar to RAL 9016) with square 4-row lens arrays for high-efficiency light yield.Diffuser held in the luminaire housing with spring catches, hinges down on both sides. LED modules formed as a flat board. Mid-power LEDs for even illumination and maximum efficiency. LED driver prefitted in luminaire housing.
0837788 - LENSES-EUE1249DAWS830B0350
Control: DALI
Colour temperature: 3000 K
Luminous flux (lm): 3430
Power (W): 21
Efficiency (lm/W): 164
0837784 - LENSES-EUE1249DAWS840B0350
Control: DALI
Colour temperature: 4000 K
Luminous flux (lm): 3570
Power (W): 21
Efficiency (lm/W): 170
0827788 - LENSES-EUE1249NDWS830B0350
Control: On/Off
Colour temperature: 3000 K
Luminous flux (lm): 3430
Power (W): 21
Efficiency (lm/W): 164
0827784 - LENSES-EUE1249NDWS840B0350
Control: On/Off
Colour temperature: 4000 K
Luminous flux (lm): 3570
Power (W): 21
Efficiency (lm/W): 170
2. Ceilings with concealed T-bars and symmetric mineral fibre and plasterboard tiles
3. Ceilings with concealed T-bars and symmetric metal tiles
4. Ceilings with exposed T-bars and lay-in ledged or grooved ceiling boards
5. Ceilings with concealed support rails and asymmetric mineral fibre board
6. Continuous trim strip ceilings with mineral fibreboard or metal tile ceilings
7. Metal plank systems Luminaire mounting parallel to the planks
8. Recessed luminaires for sports halls for Wilhelmi-type mineral fibre board ceilings
9. Recessed luminaires for sports halls for metal plank ceilings, modular dimension 100 (75 + 25 or 84 + 16)
4 Articles
| Item number - Designation | Control | Colour temperature | Luminous flux (lm) | Power (W) | Efficiency (lm/W) | Download | Wishlist |
| 0837788 - LENSES-EUE1249DAWS830B0350 | DALI | 3000 K | 3430 | 21 | 164 |
|
|
| 0837784 - LENSES-EUE1249DAWS840B0350 | DALI | 4000 K | 3570 | 21 | 170 |
|
|
| 0827788 - LENSES-EUE1249NDWS830B0350 | On/Off | 3000 K | 3430 | 21 | 164 |
|
|
| 0827784 - LENSES-EUE1249NDWS840B0350 | On/Off | 4000 K | 3570 | 21 | 170 |
|
|
